This printer is designed for efficiency and versatility, featuring an adjustable paper warehouse that supports a wide range of printing papers, thermal printing technology that eliminates the need for ribbons or consumables, and a dual media sensor for fast, precise paper positioning. With support for label widths of up to 110mm and compatibility with CPCL and TSPL programming languages, it delivers powerful, hassle-free printing for all your business needs.
| Specifications |
|
Interfaces |
USB / LAN / Bluetooth / WIFI |
|
Print Comand |
CPCL / TSPL command (ESC/POS command) |
|
Print Method |
Direct Line Thermal |
|
Pirnt Speed |
160mm/sec (MAX) |
|
Resolution |
203DPI (8dot/mm) |
|
Inner Code |
Supported 11 types font size |
|
Paper |
|
Thermal Paper Types |
continuous paper, label paper, folded paper, tag paper |
|
Effective Print Width |
100mm (Max 800 points) |
|
Available Max Paper Width |
110 ± 0.5mm |
|
Paper Thickness |
0.06-0.30 mm |
|
Electrical |
|
Charging Method |
external charger DC 24V/2.5A |
|
Physical |
|
Printer Dimension |
226x180x147mm |
|
Unit Weight |
2 kgs （with accessories) |
|
Pieces per CTN |
8 pcs |
|
CTN Dimension |
60×39.6×34.4 CM |
|
G.W. per CTN |
17 kgs |
|
Environmental |
|
Operating Temperature |
+0 ℃ ~ 50 ℃ (no condensation allowed) |
|
Working Humidity |
20% ~ 85% RH (no condensation allowed) |
|
Storage Temperature |
-20 ℃ ~ 60 ℃ (no condensation allowed) |
|
Storage Humidity |
5% ~ 95% RH (no condensation allowed) |
|
Mechanical Noise |
less than 60dB (A-weighted RMS) |
